Enfòmasyon debaz
non pwodwi: Kout chèn CONVEYOR ak broch pwolonje
Nimewo pwodwi: 08A (40)
Gwoup pwodwi: Conveyor chèn
pwopriyete pwodwi yo
Materyèl: Alyaj/ Carbon Asye
Transpò pake: Ekspòtasyon pake
espesifikasyon: ISO9001
trademark:DUNPAI
DIN / ISO chèn No: 06c 08A 10A 12A 16A 20A 24A 28A ....
Chenn Pitch: 9.525 12.7 15.875 19.05 25.4 31.75 38.1 ...
Estrikti (pou Chèn): Roller Chain
Kout chèn CONVEYOR ak materyèl broch pwolonje: Alyaj Asye Tretman sifas: Tire Peening / Blueing Chèn : Idustry machin DIN / ISO CHÈN NO. PITCH 06C 9.525 08A 12.70 10A 15.875 12A 19.05 16A 25.4 20A 31.75 24A 38.1 28A 44.45 32A 50.8 08B 12.7 10B 19.05 12B 19.05 16B 25.4 20B 31.75 24B 25.4 28B 44.45 32B 50.8
|
|
|
 |
|
DIN / ISO chèn Non. |
AnSI chèn No. |
P (mm) |
b1,mm |
d2(madanm) |
L3(mm) |
L(mm) |
Lc(mm) |
|
06C |
35 |
9.525 |
4.77 |
3.58 |
9.5 |
20.8 |
21.6 |
|
08A |
40 |
12.700 |
7.85 |
3.96 |
9.5 |
25.1 |
26.2 |
|
10A |
50 |
15.875 |
9.40 |
5.08 |
11.9 |
31.3 |
33.1 |
|
12A |
60 |
19.050 |
12.57 |
5.94 |
14.3 |
38.6 |
40.6 |
|
16a |
80 |
25.400 |
15.75 |
7.92 |
19.1 |
50.3 |
53.3 |
|
20A |
100 |
31.750 |
18.90 |
9.53 |
23.8 |
61.8 |
66.1 |
|
24A |
120 |
38.100 |
25.22 |
11.10 |
28.6 |
76.4 |
80.4 |
|
28A |
140 |
44.450 |
25.22 |
12.70 |
33.3 |
84.8 |
89.4 |
|
32A |
160 |
50.800 |
31.55 |
14.27 |
38.1 |
99.6 |
104.4 |
|
08B |
12.700 |
7.75 |
4.45 |
9.5 |
25.1 |
26.6 |
|
|
10B |
15.875 |
9.65 |
5.08 |
11.9 |
30.1 |
31.5 |
|
|
12B |
19.050 |
11.68 |
5.72 |
14.3 |
35.4 |
37.1 |
|
|
16b |
25.400 |
17.02 |
8.28 |
19.1 |
53.0 |
54.3 |
|
|
20B |
31.750 |
19.56 |
10.19 |
41.1 |
79.9 |
83.6 |
|
|
24B |
38.100 |
25.40 |
14.63 |
50.7 |
101.4 |
105.8 |
|
|
28B |
44.450 |
30.99 |
15.90 |
61.9 |
124.0 |
128.4 |
|
|
32B |
50.800 |
30.99 |
17.81 |
64.8 |
126.8 |
131.8 |
|
|
Baj popilè: kout chèn CONVEYOR ak broch pwolonje, Lachin, Swèd, manifaktirè, faktori, te fè nan Lachin
